System principle: Transformer is a device that changes AC voltage by using electromagnetic induction principle. The product is developed with reference to the latest CNC servo system parameters. The basic function of the conventional transformer is to change the input voltage to the output voltage, so that the equipment with different grid voltage in different countries can achieve the purpose of universal matching through the voltage conversion of small transformer. The main components are primary coil, secondary coil and core (silicon steel sheet). In electrical equipment and wireless circuit, it is often used for voltage rise and fall, matching impedance, safety isolation, etc. Transformer is a kind of static electromagnetic device, which can convert the alternating current energy of one voltage into the alternating current energy of another voltage at the same frequency. The main components of transformer are a core and two or more groups of wire groups sheathed on the core. The coil connected to the input power supply of the transformer receives AC energy, which is called primary line group or primary line group. The coil connected with load sends out AC energy, which is called secondary line group or secondary line group.
Technical parameters: For the product model, please refer to the appearance and type selection instructions on the product summary page Equipment capacity 1kva-2000kva (1kVA ≠ 1kW, 1kVA ≈ 0.8kw) Phase number 1 ∮ 2W 3 ∮ w 3 ∮ 4W Input voltage 110V 200V 220V 240V 380V 415V 440V 460V 480v 660V (special customized) Output voltage 110V 120V 190V 200V 208v 220V 380V 415V 460V 660V (special customizable) Efficiency ≥ 98% Voltage change rate ≤± 1% (related to input voltage standard value) Insulation class H Withstand strength 3000V silent wear (one minute) Noise level < 60dB (80cm leveling distance test) The cooling mode of dry series is self cooling or forced cooling by fan; oil type series is oil immersed and self cooling; water cooling series loop water cooling waveform is distortion free (relative input waveform)
Functional features: 1. The products meet the standards of iec60076, GB 1094.0-2007 and cns13390 2. It is suitable for the place with AC frequency 45 ~ 65Hz and voltage ≤ 660V 3. Input and output voltage specifications can be customized according to equipment requirements 4. Wiring mode and insulation level can be customized according to customer requirements 5. Use high quality materials to maintain good electrical properties and mechanical strength 6. The use of fixed terminal block, beautiful and durable, high security 7. The special core is heat stewed, and its own consumption is very low 8. Full load rated current continuous use, long service life
|
